・Each module is equipped with an indepent BMS system. ・Safe lithium ion phosphate battery cell. ・Compact size ultralight module. ・Compact and fashionable design fits in your sweet home environment. ・Simple fixing minimize the installation time and cost.
INQUIRY NOWCapacity | 28.8KWH |
Voltage | 48V |
Nominal Voltage | 48V |
Nominal Voltage Range | 45V-54V |
Charge Cut-off Voltage | 54V |
Discharge Cut-off Voltage | 40.5V |
Max. Charge&Discharge Current | 100A |
Recommend Charge&Discharge Current | 50A |
Standard Charge Current | 50A |
Max Output Power | 28800Wh |
Discharge DOD | 90% |
Communication Port | RS485/CAN |
Cycle Times | >6000@25℃ |
Working Temperature | Discharge:-10~45℃ Charge:0~45℃ |
Warranty | 6 Years |
Battery Cell Material | Lithium(LiFePO4) |
Certification | CE,IEC62619(Cell&Pack),UL1973,CEC,UN38.3 |
Product dimension | 480*550*155mm |
