・All-in-1 solar system: 1*5kva inverter + 1*5kwh battery. ・Low voltage battery system: 51.2V. ・Expandable System. ・Safest Battery & Perfect Compatibility. ・Natural cooling & Easy Installation. ・Certifications Available.
INQUIRY NOWModel | YF-ENGBOX-LV5.1 |
Capacity | 5.12KWH |
Voltage | 48V |
Nominal voltage | 51.2V |
Nominal voltage range | 44.8-57.6V |
Charge cut-off voltage | 57.6V |
Discharge cut-off voltage | 44.8V (Recommend discharge cut-off voltage = 46V) |
Max. Charge & discharge current | 100A |
Recommend Charge & discharge current | 50A |
Max Output power | 5120Wh |
Discharge DOD | 90% |
Communication Port | RS485/CAN |
Communication Mode | WIFI / BLUETOOTH |
Ingress protection | IP20 |
Cycle times | >6000 @25℃ |
Working temperature | Discharge:-20~45℃ Charge:0~45℃ |
Warranty | 6 years |
Battery Cell Material | Lithium (LiFePO4) |
Certification | CE, IEC62619(Cell&Pack),UL1973,CEC,UN38.3 |
