・Pure sine wave output. ・Can support WIFI/GPRS. ・MPPT efficiency max 98%. ・DC start & automatic self-diagnostic fuction. ・High efficiency design for optimized battery performance. ・Selectable charging current based on applications.
INQUIRY NOWModel | YF-FS-WM 3024 |
Output Power: | 3000VA/2400W |
Input Voltage Range: | 154-264VAC±3V |
Battery Model Output Voltage: | 220VAC±3%, 50/60Hz |
Battery Model Output Wave: | Pure Sine Wave |
Load Peak Ratio: | Max(3:1) |
Battery Voltage: | 24VDC |
Battery Charging Voltage: | 27VDC |
Max. PV Array Power: | 1600W |
Solar Input Voltage Range: | 30V-150VDC |
Max. PV Display Open Circuit Voltage: | 150VDC |
Max. Solar Charging Current: | 60A |
Operating Temperature: | 0℃~40℃ |
