・Compact Size & Light Weight.
・High Power Output & Usable Energy Ratio.
・Expandable System.
・Safest Battery & Perfect Compatibility.
・Natural cooling & Easy Installation.
・Certifications Available.
INQUIRY NOWNomin
Safe and Long life cycle, the cell belongs to lithium iron phosphate power cell which can be recycled more than 5000 times.
Intelligent BMS, intelligent battery protection system make the battery more stable and safer.
Comprehensive compatibility, It is better suited for off-grid inverters and hybrid inverters.
al VoNominal Voltage:51.2Vltage:51.2V
Model | YF-LFP-256100 |
Capacity | 2.56KWH |
Voltage | 24V |
Nominal voltage | 25.6V |
Nominal voltage range | 20.8-27.2V |
Charge cut-off voltage | 27.2V |
Discharge cut-off voltage | 20.8V |
Max. Charge & discharge current | 50A |
Recommend Charge & discharge current | 40A |
Max Output power | 2560Wh |
Discharge DOD | 90% |
Ingress protection | IP65 |
Cycle times | >5000 @25℃ |
Working temperature | -10~60℃ |
Warranty | 3 years |
Battery Cell Material | Lithium (LiFePO4) |
Certification | CE, IEC62619(Cell&Pack),UL1973,CEC,UN38.3 |
