Yuhui Aurora Leading solar lighting manufacturer sorted out the following points for you to install solar street lights.
1. The components of each part are fixed:
To install the solar street lamp, the components of each part are required to be fixed, the solar panel is fixed on the solar panel bracket, the lamp holder is fixed to the arm, and then the bracket and the arm are fixed to the main pole, and the connecting wire is passed to the control box (battery box). Before lifting the light pole, first check whether the fasteners of each part are firm, whether the lamp holder is installed correctly, and whether the light source works normally.
2. Debugging system work:
Debug the system to see if the system is working normally, loosen the connection wire of the solar panel on the controller, the light source is working normally, connect the connection wire of the solar panel, and the light is off; at the same time, carefully observe the changes of the indicators on the controller, and all the data are normal. It can be hoisted and installed.
3. Pay attention to safety precautions when lifting the light pole:
The screws must be tightened properly. If the component's sun-facing angle is deviated, you need to go up and adjust its sun-facing direction to face south.
4. Battery connection controller:
Put the battery into the battery box, connect the connecting wire to the controller according to the technical requirements, first connect the battery, then the load, and then the solar panel; when wiring, be sure to pay attention to the wiring and the terminal marked on the controller. Wrong connection, the positive and negative polarities cannot collide, and cannot be connected reversely, otherwise the controller will be damaged.
5. Debug again to see if the system can operate normally:
Loosen the solar panel connection line on the controller, the solar street light source is on, connect the solar panel connection line, and the light is off; at the same time, carefully observe the changes of the indicators on the controller, and all data is normal before sealing the control box.
Author: Yufai
